Recurrent superior orbital fissure syndrome associated with VEXAS syndrome
Journal of Ophthalmic Inflammation and Infection volume 13, Article number: 39 (2023)
To describe a case of recurrent orbital inflammation and superior orbital fissure syndrome associated with VEXAS (vacuoles, E1 enzyme, X-linked, auto-inflammatory, somatic) syndrome.
VEXAS syndrome is a recently identified multi-system inflammatory disease of late adult onset. The authors describe the case of a 76-year-old man who presented with recurrent episodes of orbital inflammation, with superior orbital fissure syndrome, dacryoadenitis and orbital myositis. He had a constellation of systemic disorders including recurrent chest infections, congestive cardiac failure, pulmonary emboli and skin rashes. The underlying diagnosis of VEXAS syndrome was confirmed by genetic testing, which revealed the UBA1 mutation.
VEXAS syndrome should be considered in the differential diagnosis of orbital inflammatory disease associated with multi-system inflammatory disorders.
First described by Beck et al. in 2020, VEXAS (vacuoles, E1 enzyme, X-linked, auto-inflammatory, somatic) syndrome is a rare and potentially lethal disease characterized by multi-system inflammatory and or hematological disorders caused by somatic mutations in ubiquitin activating enzyme 1 (UBA1) in hematopoietic progenitor cells . UBA1 is an X-linked gene that encodes E1 activating enzyme, which is essential for ubiquitylation-dependent intracellular protein degradation and cell homeostasis. In VEXAS syndrome, a somatic mutation (acquired later in life) in UBA1 in hematopoietic progenitor cells leads to reduced cytoplasmic expression of E1 activating enzyme. As a result, there is upregulation of inflammatory cytokines such as IFN-γ, IL-8 and IP-10, causing systemic inflammation with multi-organ involvement. The majority of patients with VEXAS syndrome are older men, with a median age of 74 years at diagnosis . Rarely, VEXAS syndrome has also been reported in women, which is thought to arise through X-inactivation. Genome-driven studies report the prevalence of disease-causing UBA1 variants as 1 in 4269 males older than 50 years, and 1 in 26 238 women older than 50 years . As the condition has only recently been identified, patients may be diagnosed months to years after symptom onset. In one notable case, a patient was diagnosed with VEXAS posthumously, 8 years after his first symptoms .
Common clinical features in VEXAS syndrome include arthritis, relapsing polychondritis, vasculitis, cytopenia and macrocytic anemia, in the presence of raised inflammatory markers and constitutional symptoms such as fatigue, weight loss and fevers . Various ophthalmic manifestations have also been documented including ocular, periorbital and orbital inflammatory syndromes. The authors describe a case of recurrent orbital inflammation with superior orbital fissure syndrome, dacryoadenitis, and orbital myositis associated with VEXAS syndrome, and review the literature on VEXAS syndrome ophthalmic manifestations.
A 76-year-old man was referred with recurrent episodes of right orbital inflammation, each lasting for less than a week before spontaneously resolving. He had no medical history of note 6 months prior to his ophthalmic symptoms, when he developed unexplained intermittent pyrexia, recurrent chest infections, congestive cardiac failure and thromboembolic events (Table 1), requiring multiple hospitalizations including intensive care. Six months later, he presented with complete right blepharoptosis, preceded by 5 days of painless right upper lid swelling and redness, and partial ophthalmoplegia (elevation, adduction, and abduction deficit). Magnetic resonance imaging of the head and orbits was unremarkable, and the eyelid swelling completely resolved within few days without treatment, although there was mild residual blepharoptosis.
Two months later, he presented with severe right ophthalmoplegia, proptosis, periorbital edema and conjunctival chemosis (Fig. 1A-C), with visual acuities of 20/50 in the right eye and 20/32 in the left eye, normal pupillary reactions, and no signs of intraocular inflammation. Computed tomography of the orbits demonstrated soft tissue swelling in the anterior orbit, enlargement of the right lacrimal gland and extraocular muscles (notably the levator palpebrae superioris/superior rectus complex and lateral rectus) (Fig. 1D, E), intraconal fat stranding, subtle thickening of the optic nerve sheath, enlargement of the anterior right cavernous sinus, and soft tissue changes within the superior orbital fissure and orbital apex (Fig. 1D), but no discrete collection or paranasal sinus opacification. The orbital inflammation improved significantly after one week of systemic antibiotics (Fig. 1F), but there was mild residual right relative proptosis (1-2 mm), moderate blepharoptosis, and a slight right abduction and elevation, which remained stable at one-year follow up.
Meanwhile, he was undergoing investigations for a suspected multi-organ inflammatory disorder (summarized in Table 1). DNA analysis from bone marrow revealed a mutation in UBA1, confirming the diagnosis of VEXAS syndrome. He was treated with prednisolone (starting with 20 mg daily, reducing by 2.5 mg each week to zero) and hydroxychloroquine 200 mg daily. At one-year follow-up, his ophthalmic condition remained stable, with no further recurrence.
Ophthalmic involvement has been observed in up to 40% of VEXAS syndrome patients, with episcleritis, scleritis, and uveitis being the most common manifestations, and orbital and periorbital inflammation occurring less frequently.
A literature review for English language publications with the keyword “VEXAS” produced 85 results, of which 21 articles described ocular features in VEXAS syndrome (summarized in Table 2). Periorbital edema is the most common ocular adnexal finding, with other manifestations including orbital inflammation or cellulitis, orbital myositis, dacryoadenitis, optic perineuritis, or oculomotor nerve paresis.
Systemic corticosteroids are the mainstay of management for VEXAS syndrome,  including its ophthalmic manifestations, although orbital involvement may be self-limiting, as observed in our case. Various steroid-sparing medications, such as mycophenolate and methotrexate, have been shown to be beneficial in the long-term management of VEXAS syndrome. Tocilizumab (a monoclonal IL-6 receptor inhibitor) and ruxolitinimib (a JAK inhibitor) have also been found to be effective in controlling the disease . Azacitidine (a hypomethylating agent) has been reported to be effective in selected patients with VEXAS and associated myelodysplastic syndrome . Furthermore, there have been promising results following allogeneic hematopoeitic stem cell transplant, with some patients achieving complete disease remission .
The current case represents a rare ophthalmic manifestation of VEXAS syndrome, with recurrent orbital and anterior cavernous sinus/superior orbital fissure syndrome, orbital myositis, and dacryoadenitis; the ophthalmoplegia being probably caused by a combination of myositic and paralytic factors. Despite the self-limiting inflammatory syndrome and long-term immunosuppressive therapy, the patient had mild persistent ophthalmoplegia and blepharoptosis.
When orbital inflammatory syndrome secondary to systemic disease is suspected, a detailed history, systemic review, and laboratory evaluations are paramount. This approach includes a full blood count, metabolic panel, thyroid function tests, inflammatory markers, and an autoimmune profile encompassing anti-nuclear antibodies (ANA), antineutrophil cytoplasmic antibodies (ANCA), serum angiotensin-converting enzyme (ACE) and immunoglobulin G4 (IgG4) levels. CT and MRI scans may reveal a spectrum of findings such as enhancing orbital mass, uveoscleral thickening, enlarged extraocular muscles or lacrimal glands, diffuse inflammatory changes, apical lesions, cavernous sinus or paranasal sinuses involvement. Positron emission tomography (PET) scans may also be useful in detecting multi-system inflammatory disease or malignancy. If clinical and imaging results remain ambiguous, orbital biopsy is advised to identify the cause of the orbital inflammation. In the current case, blood tests and orbital imaging indicated an inflammatory process, within the context of multi-system disease and constitutional symptoms such as fatigue, muscle wasting and weight loss. The diagnosis of VEXAS in the current case was ultimately confirmed by bone marrow biopsy and genetic testing.
In summary, VEXAS syndrome should be considered in the differential diagnosis of orbital inflammatory syndromes, particularly in older patients who have multi-organ inflammation and or haematological disorders. With a broad spectrum of clinical manifestations, patients may be under the care of multiple specialists for seemingly unrelated inflammatory conditions, until the unifying diagnosis of VEXAS is confirmed by genetic testing for the UBA1 mutation.
Availability of data and materials
Data sharing is not applicable to this article as no datasets were generated or analysed during the current study.
Beck DB, Ferrada MA, Sikora KA et al (2020) Somatic mutations in UBA1 and severe adult-onset Autoinflammatory Disease. N Engl J Med 383:2628–2638
Koster MJ, Kourelis T, Reicard KK et al (2021) Clinical heterogeneity of the VEXAS syndrome: a Case Series. Mayo Clin Proc 96(10):2653–2659
Beck DB, Bodian DL, Shah V et al (2023) Estimated prevalence and clinical manifestations of UBA1 variants Associated with VEXAS Syndrome in a Clinical Population. JAMA 329(4):318–324
Midtvedt Ø, Stray-Pedersen A, Andersson H et al (2022) A man in his sixties with chondritis and bone marrow failure. Tidsskr nor Laegeforen 142(4)
Georgin-Lavialle S, Terrier B, Guedon AF et al (2022) Further characterization of clinical and laboratory features in VEXAS syndrome: large-scale analysis of a multicentre case series of 116 french patients. Br J Dermatol 186(3):564–574
Barba T, Jamilloux Y, Durel CA et al (2021) VEXAS syndrome in a woman. Rheumatology (Oxford) 60(11):e402–e403
Staels F, Betrains A, Woei-A-Jin FJSH et al (2021) Case Report: VEXAS Syndrome: from mild symptoms to life-threatening macrophage activation syndrome. Front Immunol 12:678927
van der Made CI, Potjewijd J, Hoogstins A et al (2022) Adult-onset autoinflammation caused by somatic mutations in UBA1: a dutch case series of patients with VEXAS. J Allergy Clin Immunol 149(1):432–439
Ciferska H, Gregová M, Klein M et al (2022) VEXAS syndrome: a report of three cases. Clin Exp Rheumatol 40(7):1449
Khitri MY, Guedon AF, Georgin-Lavialle S et al (2022) Comparison between idiopathic and VEXAS-relapsing polychondritis: analysis of a french case series of 95 patients. RMD Open 8(2):e002255
Neupane K, Jayarangaiah A, Zhang Y, Kumar A (2022) VEXAS syndrome with progression of MDS to MDS/MPN overlap syndrome. BMJ Case Rep 15(12):e251089
Topilow JS, Ospina Cardona D, Beck DB, Ferrada MA, McMahan ZH, Paik JJ (2022) Novel genetic mutation in myositis-variant of VEXAS syndrome. Rheumatology (Oxford) 61(12):e371–e373
Holmes A, Thant A, Correy R, Vilain R (2023) Inflammatory pseudotumour arising secondary to VEXAS syndrome. Pathology 55(1):161–163
Templé M, Duroyon E, Croizier C et al (2021) Atypical splice-site mutations causing VEXAS syndrome. Rheumatology (Oxford) 60(12):e435–e437
Al-Hakim A, Poulter JA, Mahmoud D et al (2022) Allogeneic haematopoietic stem cell transplantation for VEXAS syndrome: UK experience. Br J Haematol 199(5):777–781
Ciprian G (2022) Adverse reaction to COVID-19 mRNA vaccination in a patient with VEXAS Syndrome. Cureus 14(3):e23456
Lacombe V, Prevost M, Bouvier A et al (2021) Vacuoles in neutrophil precursors in VEXAS syndrome: diagnostic performances and threshold. Br J Haematol 195(2):286–289
Magnol M, Couvaras L, Degboé Y et al (2021) VEXAS syndrome in a patient with previous spondyloarthritis with a favourable response to intravenous immunoglobulin and anti-IL17 therapy. Rheumatology (Oxford) 60(9):e314–e315
Kunishita Y, Kirino Y, Tsuchida N et al (2022) Case Report: Tocilizumab Treatment for VEXAS Syndrome with Relapsing Polychondritis: a Single-Center, 1-Year longitudinal observational study in Japan. Front Immunol 13:901063
Lee SMS, Fan BE, Lim JH, Goh LL, Lee JSS, Koh LW (2021) A case of VEXAS syndrome manifesting as Kikuchi-Fujimoto disease, relapsing polychondritis, venous thromboembolism and macrocytic anaemia. Rheumatology (Oxford) 60(9):e304–e306
Lötscher F, Seitz L, Simeunovic H et al (2022) Case Report: genetic double strike: VEXAS and TET2-Positive myelodysplastic syndrome in a patient with Long-Standing Refractory Autoinflammatory Disease. Front Immunol 12:800149
Goyal A, Narayanan D, Wong W et al (2022) Tocilizumab for treatment of cutaneous and systemic manifestations of vacuoles, E1 enzyme, X-linked, autoinflammatory, somatic (VEXAS) syndrome without myelodysplastic syndrome. JAAD Case Rep 23:15–19
Beecher MB, Tong JY, Halliday LA, Hissaria P, Selva D (2022) Recurrent orbital inflammation associated with VEXAS syndrome. Orbit 1–4
Martín-Nares E, Vargas-Serafín C, Delgado-de la Mora J et al (2022) Orbital and periorbital inflammation in VEXAS syndrome. Scand J Rheumatol 51(4):338–341
Heiblig M, Ferrada MA, Koster MJ et al (2022) Ruxolitinib is more effective than other JAK inhibitors to treat VEXAS syndrome: a retrospective multicenter study. Blood 140(8):927–931
Comont T, Heiblig M, Rivière E et al (2022) Azacitidine for patients with vacuoles, E1 Enzyme, X-linked, autoinflammatory, somatic syndrome (VEXAS) and myelodysplastic syndrome: data from the french VEXAS registry. Br J Haematol 196(4):969–974
The authors have no sources of funding to declare.
Ethics approval and consent to participate
This report adheres to the principles of the Declaration of Helsinki.
Consent for publication
The authors obtained consent from the patient to publish their individual details and images.
The authors declare no competing interests.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
About this article
Cite this article
Myint, K., Patrao, N., Vonica, O. et al. Recurrent superior orbital fissure syndrome associated with VEXAS syndrome. J Ophthal Inflamm Infect 13, 39 (2023). https://doi.org/10.1186/s12348-023-00362-1
