Frosted branch angiitis presenting after a SARS-CoV-2 infection

Abstract

Purpose

To report a case of frosted branch angiitis presenting in a pediatric patient with unremarkable laboratory work-up apart from SARS-CoV-2 IgG antibodies.

Observations

Less than four weeks after a SARS-CoV-2 infection, a 10 year-old female presented to the emergency department with severe headache and intermittent fevers. During her hospital admission, the ophthalmology service was consulted for blurry vision. Subsequent eye examination revealed frosted branch angiitis. The patient initially received intravenous corticosteroids but was escalated to plasmapheresis to achieve resolution of her symptoms. Outpatient maintenance therapy consisted of an oral Prednisone taper and Infliximab infusion.

Conclusion and importance

This case represents a unique ocular manifestation of COVID-19, as recent SARS-CoV-2 was the sole identifiable cause of the patient’s frosted branch angiitis. Additionally, this patient required plasmapheresis to control disease progression.

Introduction

Frosted branch angiitis is a descriptive term for a retinal vasculitis that presents with significant lymphoplasmacytic infiltration of the perivascular space. Clinically, this appears like frosted branches of a tree [1].

Patients are usually affected in a bimodal age distribution, one peak in early childhood and another into the second or third decade of life, with a predominance of females to males. Frosted branch angiitis can present as an idiopathic disorder or secondary to a systemic condition. It has been associated with sarcoidosis, syphilis, tuberculosis [2], multiple sclerosis, systemic lupus erythematosus [3], pars planitis, tuberculous retinal vasculitis, cytomegalovirus [4] (CMV), herpes simplex virus (HSV), herpes zoster virus (HZV), acquired immunodeficiency syndrome (AIDS), toxoplasmosis, Bechet’s [5], Crohn’s disease, malignancy [6], and paraneoplastic syndromes [7].

In cases of infectious etiologies, most notably CMV, frosted branch angiitis can be the result of direct infection of retinal vasculature [8, 9]. When direct involvement is ruled out, frosted branch angiitis is thought to be the result of hypersensitivity-mediated deposition of immune complexes in the setting of infectious and autoimmune etiologies described above [8]. In up to 33% of cases, there is no confirmed etiology apart from a presumed viral prodrome, with these cases classified by Kleiner as “acute idiopathic” FBA [1, 8].

A targeted work up is appropriate if a patient presents with a known underlying condition. Otherwise, an ocular presentation may be the first symptom of an underlying systemic condition. An extensive work up begins with a thorough ophthalmic exam including indirect fundus examination, optical coherence tomography of the macula and nerve, and fluorescein angiography. Visual Field and an electroretinography could help aid in diagnosis and prognostic assessment. Infectious workup, such as viral titers, may be beneficial if demonstrated to be negative. Laboratory and imaging studies for both infectious and auto-immune etiologies are summarized in Table 1 below. If there are accompanying neurological signs, investigation with lumbar puncture and MRI imaging may be considered.

Table 1 Introductory imaging and laboratory studies for frosted branch angiitis

Most cases of frosted angiitis reported between 1976 and 2003 have been treated with systemic steroids and/or acyclovir in cases of herpetic etiology and systemic steroids in autoimmune or idiopathic etiologies. These patients mostly had rapid resolution and recovery of vision. A total of 10% of these reported cases have a final visual acuity of 6/60 or worse. Complications include an epiretinal membrane, retinal fibrosis, and atrophic lesions [8]. Finally, recurrence of the disease is typically rare, though there has been a reported case of secondary frosted branch angiitis due to toxoplasmosis that recurred twice after initial treatment [10].

Case report

A 10 -year-old female presented to the emergency department with a persistent severe headache, intermittent fevers and a SARS-CoV-2 infection less than four weeks prior. (This presentation was prior to the availability of COVID-19 vaccinations.) A few days into her hospital stay, the ophthalmology service was consulted for blurry vision. On bedside examination, her near visual acuity was 20/400 in each eye, with mild vitreous inflammation noted on slit lamp examination. Fundoscopic examination of both eyes demonstrated optic disc and macular edema, intra-retinal hemorrhages, and peripheral vascular sheathing consistent with frosted angiitis (Figs. 1 and 2).

Fig. 1
figure 1

Bedside indirect Ophthalmoscopy of the left eye showing exudative retinal detachment. Image has been inverted to focus on the superior arcade

Fig. 2
figure 2

Bedside indirect ophthalmoscopy of the left eye showing perivascular sheathing consistent with “frosted branch” angiitis, and retinal hemorrhages. Image has been inverted to focus on the superior arcade

On neurological examination, pertinent positives included altered mental status and an afferent pupillary defect (APD). However, the APD was noted following her serous detachment. The patient demonstrated normal reflexes with no focal weakness or altered muscle tone.

Comprehensive laboratory work up demonstrated the following pertinent positives: lumbar puncture with an elevated intracranial pressure (32 cm3, Normal 7.5-20 cm3), elevated D-dimer (0.71 mcg/mL, Normal < 0.50), elevated ACE (3.2 unit/L) and positive SARS COV2 IgG and negative IgM antibodies. Testing for underlying rheumatological, viral, fungal, and bacterial etiologies are summarized in Table 2. Anterior Chamber (AC) tap was deferred due to negative infectious work-up and completion of a lumbar puncture. Given the consideration for a post-viral inflammatory consideration, neuro-imaging was obtained. This demonstrated concerns for increased T2 hyperintensity in the bilateral medial temporal lobes but was otherwise negative for evidence of cerebral vasculitis, infection, or demyelination.

Table 2 Summary of laboratory testing and results

Her visual status declined to hand motion when she developed a serous retinal detachment in the left eye. Intravenous corticosteroids (15 mg Methylprednisolone q6 hours for ten days) were initiated with no improvement. Seven days of IV corticosteroids yielded no improvement, with persistent headaches. Because of the patient’s lack of improvement in vision and systemic symptoms (headaches), plasmapheresis was initiated at 44 mL/kg with 1.1 plasma volume exchanged for a duration of 5 days. This led to marked and rapid improvement with resolution of the serous detachment. The patient was discharged on an oral prednisone taper starting with 60 mg daily. Additionally, after reviewing available treatment options with the patient’s family, the rheumatology department recommended Infliximab therapy. Accordingly, the patient received Infliximab (750 mg/m2) infusions, with last dated treatment given six months following the initial hospitalization.

On the one month outpatient follow up, visual acuity at distance was 20/300 OU. On slit lamp examination, she demonstrated trace cell in the anterior chamber with 1+ vitreous cell bilaterally. Indirect ophthalmoscope examination demonstrated residual, nasal optic nerve edema, resolution of peripheral vascular sheathing, and 360 chorioretinal scarring. Baseline optical coherence tomography demonstrated diffuse outer retinal layer disruption with edema superior to the macula OD and residual subretinal fluid OS (Fig. 3A and B).

Fig. 3
figure 3

A, B Spectrum domain optical coherence tomography-macula (SD OCT-m) of the right and left eyes, taken a month after presentation demonstrates macular edema with intraretinal hyperreflective foci and disruption of the external limiting membrane, IS/OS junction and RPE of the right eye (3A) and intraretinal hyperreflective foci, subretinal fluid and hyperreflective foci at the level of the photoreceptors and RPE of the left eye (3B). C, D SD OCT-m of the right and left eyes taken at 4 month follow-up that demonstrates improved edema with few persistent intraretinal hyperreflective foci of the right eye (3C) and resolving subretinal fluid with improvement of the IS/OS junction in the left eye

Two weeks later, the visual acuity improved to 20/80 -1 OD and 20/150 OS. Exam showed resolving inflammation in her anterior chamber with a stable posterior examination. Repeat OCT imaging demonstrated persistent outer retinal layer disruption with resolved intraretinal edema OD and resolved subretinal fluid OS (Fig. 3c and d). Oral fluorescein angiography testing demonstrated late staining along the veins of the superior arcade with temporal perivascular leakage OD and late staining of venules superiorly with peripheral vascular dropout and perivascular leakage OS.

On 9 month clinical follow up, the patient’s visual acuity was 20/25-1 OD 20/30 OS. The examination demonstrated no active inflammation (Fig. 4).

Fig. 4
figure 4

A, B and C Pseudo color wide-field fundus photographs of the left eye taken (4a) one month after presentation showing resolving serous detachment, vascular tortuosity and macular edema, and 4b six weeks after presentation. 4c taken at 4 months demonstrates return to relatively normal appearing vasculature with resolving of previously noted vascular sheathing

Discussion

Our case highlights important aspects of managing frosted branch angiitis. To begin, it requires interdisciplinary care between rheumatology, ophthalmology, hematology/oncology, infectious diseases, nephrology, and neurosurgery. Prior to ophthalmology consultation, the patient’s history and examination were suspicious for meningitis. After assessment by ophthalmology, a more targeted differential was formed and helped to guide management.

Furthemore, there are two significant aspects specific to this patient’s presentation. First, our case represents a unique ocular manifestation of COVID-19. Among patients diagnosed with COVID-19, the most common ophthalmic symptoms are dry eye, blurred vision, and foreign-body sensation [11]. There are reports of more serious involvement related to COVID-19, such as cases of unilateral retinal vasculitis and retinal vein occlusion [12,13,14]. However, the literature currently has only one reported COVI9-19 linked case of frosted angiitis, which occurred in an immunocompromised patient with positive CMV serologies [15].

Our case report adds to the literature, especially as the extensive laboratory workup had been overwhelmingly negative besides positive IgG antibodies to COVID 19 and a recently suspected infection. In this case, recent infection with SARS-CoV-2 was the only identifiable trigger for the patient’s frosted branch angiitis.

Finally, this case of frosted angiitis was refractory to intravenous corticosteroid therapy and required plasmapheresis to halt retinal progression. This is evidenced by the patient receiving IV corticosteroids for seven days without any improvement in their symptoms. There were three days of overlap, where the patient received combination of plasmapheresis and steroids. Likewise, Infliximab and Prednisone were administered as outpatient treatments. However, the initiation of plasmapheresis led to quick resolution that was noted prior to discharge. The literature does not demonstrate cases in which plasmapheresis was necessary for resolution of frosted angiitis. Though, apheresis therapy and plasmapheresis have been cited for other auto-immune related retinal vasculitis [16, 17].

Conclusions

Prior infection with SARS-CoV-2 may represent an important cause of frosted-branch angiitis. The clinician should include questioning and testing to evaluate the possibility of recent infection when investigating this cause of retinal vasculitis. Lastly, when intravenous corticosteroids are failing to improve symptoms, escalation to plasmapheresis may be necessary to achieve resolution of symptoms.

Availability of data and materials

All data generated or analyzed during this study are included in this article. Further enquiries can be directed to the corresponding author.

Abbreviations

HSV:

Herpes Simplex Virus

VZV:

Varicella Zoster Virus

AIDS:

COVID-19, Acquired Immunodeficiency Syndrome

AC:

Anterior Chamber

OCT:

Ocular Coherence Tomography

ACE:

Angiotensin-Converting Enzyme

References

  1. Kleiner RC (1997) Frosted branch angiitis: clinical syndrome or clinical sign? Retina. 17(5):370–371

    Article  CAS  PubMed  Google Scholar

  2. Zhao H, Guan J, Zhou L, Zhang Q, Si Y (2012) Frosted branch angiitis in a woman with mycobacterium tuberculosis infection. Ocul Immunol Inflamm 20(3):227–229

    Article  CAS  PubMed  Google Scholar

  3. Brêtas CO, Novelli A, Silva TGC et al (2021) Bilateral frosted branch angiitis in an initial case of systemic lupus erythematosus. Arq Bras Oftalmol 84(5):499–502

    Article  PubMed  Google Scholar

  4. Aguilar Lozano LA, Gonzalez DA (2016) Frosted branch Angiitis associated with cytomegalovirus retinitis. Ophthalmology. 123(3):645

    Article  PubMed  Google Scholar

  5. Ferreira BF, Rodriguez EE, Prado LL, Gonçalves CR, Hirata CE, Yamamoto JH (2017) Frosted branch angiitis and cerebral venous sinus thrombosis as an initial onset of neuro-Behçet’s disease: a case report and review of the literature. J Med Case Rep 11(1):104

    Article  PubMed  PubMed Central  Google Scholar

  6. Hua MT, Blaise P, De Leval L, Rakic JM (2009) Frosted branch angiitis with undiagnosed Hodgkin lymphoma. Eur J Ophthalmol 19(2):310–313. https://doi.org/10.1177/112067210901900226

    Article  PubMed  Google Scholar

  7. Alhaj Moustafa M, Crowell EL, Elmahdy S, Malkovska V, Reddy AK (2018) Paraneoplastic frosted branch angiitis as first sign of relapsed Hodgkin lymphoma. Clin Case Rep 6(10):1978–1981. https://doi.org/10.1002/ccr3.1778

    Article  PubMed  PubMed Central  Google Scholar

  8. Walker S, Iguchi A, Jones NP (2004) Frosted branch angiitis: a review. Eye. 18(5):527–533. https://doi.org/10.1038/sj.eye.6700712

    Article  CAS  PubMed  Google Scholar

  9. Secchi A, G; Tognon, M Sofia; Turrini, Barbara; carniel, Giovanni. (1992) Acute frosted retinal Periphlebitis associated with cytomegalovirus retinitis. Retina. 12(3):245–247

    Article  CAS  PubMed  Google Scholar

  10. Oh J, Huh K, Kim SW (2005) Recurrent secondary frosted branch angiitis after toxoplasmosis vasculitis. Acta Ophthalmol Scand 83(1):115–117. https://doi.org/10.1111/j.1600-0420.2005.00399.x

    Article  PubMed  Google Scholar

  11. Nuzzi R, Carucci LL, Tripoli F (2020) COVID-19 and ocular implications: an update. J Ophthalmic Inflamm Infect 10:20. https://doi.org/10.1186/s12348-020-00212-4

    Article  CAS  PubMed  PubMed Central  Google Scholar

  12. Quintana-Castanedo L, Feito-Rodríguez M, Fernández-Alcalde C et al (2020) Concurrent chilblains and retinal vasculitis in a child with COVID-19. J Eur Acad Dermatol Venereol 34(12):e764–e766. https://doi.org/10.1111/jdv.16801

    Article  CAS  PubMed  PubMed Central  Google Scholar

  13. Erdem S, Karahan M, Dursun ME et al (2021) Retinal Vasculitis case developing in the early period after COVID-19. Klin Monbl Augenheilkd 239(09):1132-1133. https://doi.org/10.1055/a-1363-1326

  14. Sen S, Kannan NB, Kumar J et al (2022) Retinal manifestations in patients with SARS-CoV-2 infection and pathogenetic implications: a systematic review. Int Ophthalmol 42(1):323–336. https://doi.org/10.1007/s10792-021-01996-7

    Article  PubMed  Google Scholar

  15. Lim TH, Wai YZ, Chong JC (2021) Unilateral frosted branch angiitis in an human immunodeficiency virus-infected patient with concurrent COVID-19 infection: a case report. J Med Case Rep 15(1):267. https://doi.org/10.1186/s13256-021-02826-1

    Article  PubMed  PubMed Central  Google Scholar

  16. Moriarty PM, Whittaker TJ (2007) Apheresis therapy for retinal Vasculitis. Arch Ophthalmol 125(10):1443. https://doi.org/10.1001/archopht.125.10.1443

    Article  PubMed  Google Scholar

  17. Papadaki TG, Zacharopoulos IP, Papaliodis G, Iaccheri B, Fiore T, Foster CS (2006) Plasmapheresis for lupus retinal Vasculitis. Arch Ophthalmol 124(11):1654–1656. https://doi.org/10.1001/archopht.124.11.1654

    Article  PubMed  Google Scholar

Download references

Acknowledgements

Not applicable.

Funding

Akhila Alapati, Nathaniel Cameron, Sean Gratton, Erin Stahl, and Mary Champion have no funding sources.

Author information

Authors and Affiliations

Authors

Contributions

All authors attest that they meet the current ICMJE criteria for Authorship. AA and NC composed the manuscript and performed literature review. MC, ES, and SG contributed to the practice management of the case, and assisted with manuscript composition. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Nathaniel Cameron.

Ethics declarations

Ethics approval and consent to participate

Ethical approval is not required for this study in accordance with local and national guidelines.

Consent to for publication

Written informed consent was obtained from the parent/legal guardian of the patient for publication of the details of their medical case and any accompanying images.

Competing interests

The authors declare that they have no competing interests.
