IgG4-related disease presenting as panuveitis without scleral involvement

Abstract

Background

The following case emphasizes the importance of including IgG4-related disease (RD) in the differential diagnosis of intraocular inflammation and multiple cranial nerve palsies.

Results

A 33-year-old man, with a history of idiopathic bilateral panuveitis, presented with a new right pupillary-sparing partial third nerve palsy, which spontaneously resolved in 2 weeks, but was followed 1 month later, by a right sixth nerve palsy, which also resolved within a few weeks. Motility disturbance was accompanied by a decrease in the central acuity in the right eye. Magnetic resonance imaging/angiography (MRI/MRA) demonstrated a densely enhancing osteodestructive skull base process extending through the cavernous sinus and into the right superior orbital fissure. Biopsy of the lesion was consistent with IgG4-related disease (RD).

Conclusions

This is the first reported case of IgG4-RD associated panuveitis without scleral involvement, expanding the list of clinical manifestations of the IgG4-RD.

Review

A 33-year-old man, with a history of bilateral idiopathic panuveitis for the past 6 years, presented with a new onset of binocular oblique diplopia and right ptosis. He was previously treated with several immunomodulators, including cyclosporine, mycophenolate mofetil, azathioprine, and methotrexate. These agents had failed in controlling his active panuveitis, and he had been receiving adalimumab infusions every 2 weeks for the past 2 years.

On initial presentation, central acuity was 20/30 in each eye; extraocular motility testing demonstrated no adduction and severely restricted supraduction in the right eye, along with almost complete right-sided ptosis. Patient was diagnosed with a right pupillary-sparing partial third nerve palsy. Biomicroscopic examination revealed bilateral mild to moderate (1/2-1+) anterior uveitis with a few anterior vitreous cells but no posterior vitritis. Fundoscopy was grossly normal.

Urgent MRI and MRA of the brain and orbits were performed and revealed a densely enhancing osteodestructive skull base process, with a lesion centered around the right sphenoid sinus and extending through the cavernous sinus into the adjacent meninges and right superior orbital fissure (Fig. 1ad). Radiological differential was between inflammatory (granulomatous non-infectious or infectious) or, less likely, neoplastic entities.

Fig. 1
figure1

Axial T1 (a) and T2 (b, c) weighted magnetic resonance imaging, pre-gadolinium, showing an osteodestructive skull base process, with a lesion centered around the right sphenoid sinus and extending through the cavernous sinus into the adjacent meninges and right superior orbital fissure. Axial (d) T1 weighted magnetic resonance imaging, post-gadolinium, showing the focus of enhancement of the lesion

When the patient was seen 2 weeks later, the right partial third nerve palsy had completely resolved. A computed tomography (CT) scanning of the brain and orbits was performed to further characterize the lesion and demonstrated a lack of normal inferior wall of the left sphenoid sinus with the small bone fragments in the sinus and a small tract extending from the left lateral sphenoid sinus wall towards the cavernous sinus. There was also an asymmetric thickening in the left posterior cavernous sinus extending to the right anterior cavernous sinus and right orbital apex (Fig. 2).

Fig. 2
figure2

Axial computed tomography scanning of the brain demonstrating an asymmetric thickening in the left posterior cavernous sinus extending to the right anterior cavernous sinus and right orbital apex

A month later, the patient started noticing diplopia again; there was complete absence of right abduction on exam compatible with a sixth nerve palsy. Central visual acuity in the right eye had deteriorated to counting fingers. There was a right RAPD, but no abnormalities on fundoscopy were noted.

CT scan of the chest, abdomen, and pelvis was obtained and was reported as normal. Multiple blood tests (complete blood count, erythrocyte sedimentation rate, C-reactive protein, antinuclear antibodies, syphilis screening, angiotensin-converting enzyme, and tuberculosis purified protein derivative skin testing) were all normal as well.

Transsphenoidal biopsy of the skull base mass was performed and demonstrated an inflammatory infiltrate with lymphocytes and slight increase in B cells with interspersed macrophages and plasma cells (Fig. 3a, b). Staining for CD20 and CD3 revealed a mixture of B and T cells. Histochemical staining for fungi and mycobacteria was negative. As the biopsy did not produce conclusive diagnostic results, a bone marrow biopsy and aspirate were performed to look for lymphomatous changes. Cytology and flow cytometry of the aspirate were both normal. Adalimumab was then discontinued as it was felt it could have been a possible culprit in the development of the skull base lesion (it has been previously reported to be associated with rare forms of lymphoma as well as increased incidence of sarcoidosis) [13].

Fig. 3
figure3

a, b Transsphenoidal biopsy of the skull base mass demonstrating an inflammatory infiltrate with lymphocytes and slight increase in B cells with interspersed macrophages and plasma cells

One month after the biopsy was performed, visual acuity spontaneously improved to 20/40 on the right. Motility deficits had all resolved and fundoscopy remained normal. There was a mild anterior uveitis with a few anterior vitreous cells and no posterior vitritis in either eye.

Lack of definitive diagnosis prompted repeat of the CT scan of the brain and orbits which was unchanged. At this point, a review of possible differential diagnosis led to another look at the results of the biopsy. IgG4 stains were requested and demonstrated an IgG:IgG4 ratio of more than 40% as well as more than 30 IgG4 positive plasma cells per high-power field (Fig. 4a, b). Serum IgG-4 levels were normal.

Fig. 4
figure4

IgG stains (a) IgG4 stains (b) demonstrated an IgG:IgG4 ratio of more than 40% as well as more than thirty IgG4-positive plasma cells per high-power field

As the patient recovered spontaneously and has not had any future relapses, no treatment was initiated and he has been followed with observation only. The panuveitis has remained controlled with topical steroid drops over the past 2 years, after the initial presentation.

Conclusions

To our knowledge, this is the first reported case of panuveitis without scleral involvement associated with IgG4-RD.

IgG4-RD is an emerging entity that has been described and reported on extensively in the recent years. It is characterized by tumefactive lesions, dense lymphoplasmacytic infiltrate abundant in IgG4-positive plasma cells, and fibrosis with typical storiform pattern and obliterative phlebitis, although the latter is only intermittently observed, depending on the affected organs [4, 5]. The disease was originally described in 2001 in a cohort of Japanese patients presenting with autoimmune pancreatitis and a raised serum IgG4 level [2, 3]. Since then, it has been described in nearly all organs, including the lungs, liver, kidney, and thyroid [4, 69].

Diagnostic criteria for IgG4-RD are still incompletely defined. An international consensus statement [10] had suggested three different levels of diagnostic classification for IgG4-RD: histologically highly suggestive of IgG4-RD, probable histologic features of IgG-RD, or insufficient histologic evidence of IgG4-RD. Other classifications [11] have attempted to include the serum IgG4 levels in the diagnostic criteria, but the serum levels can be normal in as much as 30–40% of patients (as they were in our case) with IgG4-RD thus rendering this diagnostic tool unsupportive in this cluster of patients [5, 12].

From an ophthalmological point of view, IgG4-RD most often affects the orbit or lacrimal gland [4, 9, 13]. A Japanese study reviewed 65 cases with IgG4-related ophthalmic diseases (ROD) [14] and reported 31 cases (57.7%) that had only lacrimal gland involvement, with the remaining 34 cases (52.3%) involving ocular adnexa: trigeminal nerve, extraocular muscles, orbit, eyelid and nasolacrimal duct [14]. Rare cases of conjunctival, scleral, and optic nerve involvement have also been reported [7, 15, 16].

Nearly half of the patients presenting with ocular IgG4-related ophthalmic disease will also have extraocular manifestations in other organs, and it is suggested that all patients should be evaluated for the salivary gland enlargement, lymphadenopathy, and lung, liver, and renal involvement [16]. Whole-body fluorodeoxyglucose positron emission tomography/computed tomography (FDG-PET/CT) is a valuable imaging study to assess for the extraocular manifestations of the disease [17].

In the past few years, associations between granulomatous diseases, such as sarcoidosis, adult orbital xanthogranuloma and granulomatosis with polyangiitis, and IgG4-RD have been described [15, 1821]. These cases demonstrate a possible overlap between these two conditions, although this is still not clearly understood. Interestingly, lymphoma has been associated with IgG4-RD and the latter seems to increase the risk of lymphoma [17, 2224]. Therefore, granulomatous disease and lymphoma should be considered in the differential of IgG4-RD. In the case presented here, both entities were initially considered but it was erroneously presumed that they were related to adalimumab use and not directly to IgG4-RD.

There is no clear consensus on the treatment of IgG4-RD. Spontaneous resolution has been described in the literature [25] and in our case, although the skull base lesion has remained unchanged, with the exception of mild panuveitis, the disease remained quiescent without treatment. Recurrence, however, is possible at any point in time. Corticosteroids are the first line of treatment and have been shown to be effective in treating the disease, although the relapse rate can be higher in patients treated with steroids [26]. Steroid-sparing agents have also been used successfully in treating IgG4 with rituximab (anti-CD20 monoclonal antibody) being the most successful. Dramatic responses to this anti-CD20 monoclonal antibody have been reported in the first month of treatment [27, 28]. Treatment with rituximab was suggested for our patient but, since he has remained largely asymptomatic, it was not used. Low-dose radiotherapy has also been described with variable response [17, 29].

Our report emphasizes the importance of keeping IgG4-RD in the list of differential diagnosis for patients with panuveitis and especially for patients presenting with panuveitis and eye motility abnormalities as these combinations of clinical findings are difficult to explain by a single pathological entity otherwise.

References

  1. 1.

    Lapadula G, Marchesoni A, Armuzzi A, Blandizzi C, Caporali R, Chimenti S, Cimaz R, Cimino L, Gionchetti P, Girolomoni G, Lionetti P, Marcellusi A, Mennini FS, Salvarani C (2014) Adalimumab in the treatment of immune-mediated diseases. Int J Immunopathol Pharmacol 27:33–48

    CAS  Article  PubMed  Google Scholar

  2. 2.

    Sim JK, Lee SY, Shim JJ, Kang KH (2016) Pulmonary sarcoidosis induced by adalimumab: a case report and literature review. Yonsei Med J 57:272–273

    CAS  Article  PubMed  Google Scholar

  3. 3.

    Korta DZ, Ochieng P, Fishman D, Katz SE (2015) Pulmonary sarcoidosis and latent tuberculosis in a patient with psoriasis treated with adalimumab. Dermatol Online J. 21.

  4. 4.

    Stone JH, Zen Y, Deshpande V (2012) IgG4-related disease. N Engl J Med 366:539–551

    CAS  Article  PubMed  Google Scholar

  5. 5.

    McNab AA, McKelvie P (2015) IgG4-related ophthalmic disease part I: background and pathology. Ophthal Plast Reconstr Surg 31:83–88

    Article  PubMed  Google Scholar

  6. 6.

    Hamano H, Kawa S, Horiuchi A, Unno H, Furuya N, Akamatsu T, Fukushima M, Nikaido T, Nakayama K, Usuda N, Kiyosawa K (2001) High serum IgG4 concentrations in patients with sclerosing pancreatitis. N Engl J Med 344:732–738

    CAS  Article  PubMed  Google Scholar

  7. 7.

    Ohno K, Sato Y, Ohshima K-I, Takata K, Ando M, Abd Al-Kader L, Iwaki N, Takeuchi M, Orita Y, Yoshino T (2012) IgG4-related disease involving the sclera. Mod Rheumatol. doi:10.1007/s10165-012-0758-y

    Google Scholar

  8. 8.

    Saeki T, Saitol A, Hiura T, Yamazaki H, Emura I, Ueno M, Miyamura S, Gejyo F (2006) Lymphoplasmacytic infiltration of multiple organs with immunoreactivity for IgG4: IgG4-related systemic disease. Intern Med 45:163–167

    Article  PubMed  Google Scholar

  9. 9.

    Takahira M, Kawano M, Zen Y, Minato H, Yamada K, Sugiyama K (2007) IgG4-related chronic sclerosing dacryoadenitis. Arch Ophthalmol 125:1575–1578

    Article  PubMed  Google Scholar

  10. 10.

    Deshpande V, Zen Y, Chan JK, Yi EE, Sato Y, Yoshino T, Klöppel G, Heathcote JG, Khosroshahi A, Ferry JA, Aalberse RC, Bloch DB, Brugge WR, Bateman AC, Carruthers MN, Chari ST, Cheuk W, Cornell LD, Fernandez-Del Castillo C, Forcione DG, Hamilos DL, Kamisawa T, Kasashima S, Kawa S, Kawano M, Lauwers GY, Masaki Y, Nakanuma Y, Notohara K, Okazaki K, Ryu JK, Saeki T, Sahani DV, Smyrk TC, Stone JR, Takahira M, Webster GJ, Yamamoto M, Zamboni G, Umehara H, Stone JH (2012) Consensus statement on the pathology of IgG4-related disease. Mod Pathol 137:699–711

    Google Scholar

  11. 11.

    Umehara H, Okazaki K, Masaki Y, Kawano M, Yamamoto M, Saeki T, Matsui S, Yoshino T, Nakamura S, Kawa S, Hamano H, Kamisawa T, Shimosegawa T, Shimatsu A, Nakamura S, Ito T, Notohara K, Sumida T, Tanaka Y, Mimori T, Chiba T, Mishima M, Hibi T, Tsubouchi H, Inui K, Ohara H (2012) Comprehensive diagnostic criteria for IgG4-related disease. Mod Rheumatol 22:21–30

    CAS  Article  PubMed  Google Scholar

  12. 12.

    Carruthers MN, Khosroshahi A, Augustin T, Deshpande V, Stone JH (2015) The diagnostic utility of serum IgG4 concentrations in IgG4-related disease. Ann Rheum Dis 74:14–18

    CAS  Article  PubMed  Google Scholar

  13. 13.

    Lindfield D, Attfield K, McElvanney A (2012) Sytemic immunoglobulin G4 (IgG4) disease and idiopathic orbital inflammation; removing “idiopathic” from nomenclature. Eye 26:623–629

    CAS  Article  PubMed  PubMed Central  Google Scholar

  14. 14.

    Sogabe Y, Ohshima K, Azumi A, Takahira M, Kase S, Tsuji H, Yoshikawa H, Nakamura T (2014) Location and frequency of lesions in patients with IgG4-related ophthalmic diseases. Graefes Arch Clin Exp Ophthalmol 252:531–538

    CAS  Article  PubMed  Google Scholar

  15. 15.

    Paulus YM, Cocklerham KP, Cockerham GC, Gratzinger D (2012) IgG4-positive sclerosing orbital inflammation involving the conjunctiva: a case report. Ocul Immunol Inflamm 20:375–377

    Article  PubMed  Google Scholar

  16. 16.

    Lee CS, Harocopos GJ, Kraus CL, Lee AY, Van Stavern GP, Couch SM, Rao PK (2015) IgG-associated orbital and ocular inflammation. J Ophthalmic Inflamm Infect 5:1–8

    Article  Google Scholar

  17. 17.

    McNab AA, McKelvie P (2015) IgG4-related ophthalmic disease part II: clinical aspects. Ophthal Plast Reconstr Surg 31:1–12

    Article  Google Scholar

  18. 18.

    Michel L, Clairand R, Néel A, Masseau A, Frampas E, Hamidou M (2011) Association of IgG4-related disease and sarcoidosis. Thorax 66:920–921

    Article  PubMed  Google Scholar

  19. 19.

    Mudhar HS, Bhatt R, Sandramouli S (2011) Xanthogranulomatous variant of immunoglobulin G4 sclerosing disease presenting as ptosis, proptosis and eyelid skin plaques. Int Ophthalmol 31:245–248

    Article  PubMed  Google Scholar

  20. 20.

    Singh K, Rajan KDA, Eberhart C (2010) Orbital necrobiotic xanthogranuloma associated with systemic IgG4 disease. Ocul Immunol Inflamm 18:373–378

    Article  PubMed  Google Scholar

  21. 21.

    Chang Y, Keogh KA, Lewis JE, Ryu JH, Cornell LD, Garrity JA, Yi ES (2013) IgG4-positive plasma cells in granulomatosis with polyangiitis (Wegener’s): a clinicopathologic and immunohistochemical study on 43 granulomatosis with polyangiitis and 20 control cases. Hum Pathol 44:2432–2437

    CAS  Article  PubMed  Google Scholar

  22. 22.

    Cheuk W, Yuen HK, Chan AC, Shih LY, Kuo TT, Ma MW, Lo YF, Chan WK, Chan JK (2008) Ocular adnexal lymphoma associated with IgG4+ chronic sclerosing dacryoadenitis: a previously undescribed complication of IgG4-related sclerosing disease. Am J Surg Pathol 32:1159–1167

    Article  PubMed  Google Scholar

  23. 23.

    Oyama T, Takizawa J, Nakamura N, Aoki S, Aizawa Y, Abe H (2011) Multifocal mucosa-associated lymphoid tissue lymphoma associated with IgG4-related disease; a case report. Jpn J Ophthalmol 55:304–306

    Article  PubMed  Google Scholar

  24. 24.

    Sato Y, Ohshima K, Takata K, Huang X, Cui W, Ohno K, Yoshino T (2012) Ocular adnexal IgG4-producing mucosa-associated lymphoid tissue lymphoma mimicking IgG4-related disease. J Clin Exp Hematop 52:51–55

    Article  PubMed  Google Scholar

  25. 25.

    Kase S, Yamamoto T, Ishijima K, Noda M, Ishida S (2013) Spontaneous regression of IgG4-related dacryoadenitis. Mod Rheumato 23:1018–1021

    CAS  Article  Google Scholar

  26. 26.

    Kohsroshahi A, Stone JH (2011) Treatment approaches to IgG4-related systemic disease. Curr Opin Rheumatol 23:67–71

    Article  Google Scholar

  27. 27.

    Kohsroshahi A, Bloch DB, Deshpande V, Stone JH (2010) Rituximab therapy leads to rapid decline of serum IgG4 levels and prompts clinical improvement in IgG4-related systemic disease. Arthritis Rheum 62:1755–1762

    Article  Google Scholar

  28. 28.

    Kohsroshahi A, Carruthers MN, Deshpande V, Unizony S, Bloch DB, Stone JH (2012) Rituximab for the treatment of IgG4-related systemic disease: lessons from 10 consecutive patients. Medicine (Baltimore) 91:57–66

    Article  Google Scholar

  29. 29.

    Kubota T, Moritani S, Katayama M, Terasaki H (2010) Ocular adnexal IgG4-related lymphoplasmacytic infiltrative disorder. Arch Ophthalmol 128:577–584

    Article  PubMed  Google Scholar

Download references

Funding

No funding was received for this work.

Authors’ contributions

The conception and design, acquisition of data, analysis and interpretation of data, and drafting and revising of the manuscript were done by KN, LD-D, and EM. All authors read and approved the final manuscript.

Competing interests

The authors declare that they have no competing interests.

Author information

Affiliations

Authors

Corresponding author

Correspondence to Kinda Najem.

Rights and permissions

Open Access This article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Reprints and Permissions

About this article

Verify currency and authenticity via CrossMark

Cite this article

Najem, K., Derzko-Dzulynsky, L. & Margolin, E.A. IgG4-related disease presenting as panuveitis without scleral involvement. J Ophthal Inflamm Infect 7, 7 (2017). https://doi.org/10.1186/s12348-017-0125-4
