IgG4-associated orbital and ocular inflammation
© Lee et al.; licensee Springer. 2015
Received: 2 March 2015
Accepted: 12 May 2015
Published: 29 May 2015
IgG4-associated orbital and ocular inflammation is a relatively unknown entity characterized by sclerosing inflammation with infiltration of IgG4-positive plasma cells. Some so-called idiopathic inflammation syndromes are being re-classified as IgG4-associated inflammation with histopathologic evaluation.
We report three cases with differing manifestations of IgG4-associated ocular and orbital inflammation: a case of recurrent, treatment-refractory sclero-uveitis that was diagnosed as granulomatosis with polyangiitis with an IgG4-related component, a case of pachymeningitis with optic neuritis that resulted in permanent visual loss, and a case of orbital inflammatory pseudotumor. All three would have been incompletely diagnosed without thorough histopathologic evaluation (including immunohistochemistry).
IgG4-associated disease is an idiopathic, multi-organ inflammatory state that can manifest as chronic, relapsing, sclerosing inflammation in virtually any organ system. There is a wide range of presentations in ocular and orbital inflammation. Ophthalmologists should keep IgG4-associated inflammation in mind when examining chronic, sclerofibrosing inflammation with multi-system involvement. The histology of biopsy specimens is crucial in making the correct diagnosis. Timely assessment may lead to fewer diagnostic tests and more targeted therapy.
KeywordsIgG4-associated ocular inflammation IgG4-associated orbital inflammation Histopathology
IgG4-associated disease is a relatively newly discovered entity characterized by sclerosing inflammation, a lymphoplasmacytic infiltration full of IgG4-positive plasma cells and frequently associated with elevated serum IgG4 concentrations . It was first described as a systemic condition in 2003 when extra-pancreatic manifestations were identified in patients with autoimmune pancreatitis, a condition known to be associated with elevated levels of IgG4 . Since that discovery, the presence of IgG4-related inflammation has been detected in virtually all organs, particularly the pancreas, liver, kidney, lung, and thyroid [1, 3, 4, 5]. The histopathological features exhibit remarkable consistency across organ systems. In ophthalmology, IgG4-positive sclerosing inflammation most frequently presents with involvement of the orbit/lacrimal gland [1, 5, 6], but recent case reports have described conjunctival and scleral involvement [3, 7]. We report a series of three heterogeneous patients including some unusual presentations of IgG4-associated ocular/orbital inflammatory disease: sclero-uveitis, pachymeningitis with associated bilateral optic neuropathy/perineuritis, and inflammatory pseudotumor of the orbit.
Nine months later, our patient was referred again with an exacerbation of her inflammation after cataract surgery in the right eye (performed at an outside institution). Her BCVA was 20/200. Slit-lamp examination showed mild scleral injection with a fibrotic-appearing lesion adherent to the medial sclera. Dilated fundus examination demonstrated chorioretinal scars with subretinal fibrosis and pale optic nerve. The infiltrative fibrotic lesion on the sclera was biopsied, and histologic examination revealed mixed chronic inflammatory infiltrate with fibrosis consistent with orbital inflammatory pseudotumor (Fig. 1b–d). Although no actively necrotizing vasculitis was seen, a portion of the inflammation exhibited a vasculo-centric pattern, with hyalinization of vessels, raising the possibility that these findings represented the late stage of a vasculitic process, and accordingly, granulomatosis with polyangiitis remained in the differential diagnosis (Fig. 1b, c).
Histopathology demonstrated a dense infiltrate of lymphocytes and plasma cells, with no definite vasculitis or granulomatous inflammation (Fig. 3c, d). The possibility of marginal zone lymphoma was considered but was ruled out by immunohistochemistry, with T cells (CD3-positive) outnumbering B cells (CD20-positive), and with in situ hybridization revealing a kappa:lambda ratio of <4:1 among the plasma cells (not shown). In situ hybridization for Epstein-Barr virus was negative (not shown). Additionally, molecular genetic studies did not show any evidence of a clonal IgH gene rearrangement by polymerase chain reaction (PCR). However, IgG4 immunostain was markedly positive, with 40 IgG4-positive cells per high-power field (HPF), comprising over 40 % of the total plasma cell population (Fig. 3e, f). (The total plasma cell population was assessed with CD138 immunostain, and IgG immunostain was also obtained, showing that all IgG-positive cells were also IgG4-positive, i.e., IgG4:IgG ratio of 1, not shown). Subsequent bone marrow biopsy also showed no evidence of lymphoma (small CD19-positive B-cell population with normal kappa:lambda light chain ratio), and fine-needle aspiration biopsy of a left supraclavicular lymph node showed similar findings negative for lymphoma.
On his systemic work-up, p-ANCA was borderline positive, and serum IgG showed elevated IgG4 subclasses (148.0; normal range 2.4–121.0). Accordingly, the diagnosis of IgG4-related meningeal disease was made. The patient was started on aggressive immunosuppression with high-dose corticosteroids to be followed by either cyclophosphamide or rituximab. However, due to insurance issues, he was able to receive only methotrexate. There was near-total resolution of meningeal enhancement on repeat MRI, but his visual acuity improved to only bare light perception in both eyes. He remains stable on methotrexate almost 1 year from his diagnosis.
A 76-year old man with a history of bilateral lacrimal gland masses and an otherwise unremarkable ocular examination underwent left orbital biopsy at another institution. Clinical suspicion was high for possible lymphoma due to the additional presence of cervical and axillary lymphadenopathy. The histologic diagnosis at that time was reactive lymphoid hyperplasia with fibrosis. Immunohistochemistry, kappa/lambda in situ hybridization, and flow cytometry were negative for lymphoma. The patient was lost to follow-up without any further work-up. He presented a year later due to recurrence of orbital inflammation, at which point the surgeon requested histologic work-up for IgG4-related disease. The slides from the prior orbital biopsy were requested and reviewed, showing lymphoid follicles with intervening bands of fibrosis and mixed chronic inflammatory cells. The tissue block was also received, and additional sections were cut for CD138 and IgG4 immunostaining. There were at least 150–180 IgG4-positive plasma cells per high-power field, comprising over 40 % of the total plasma cell population (as assessed by CD138). (Serum IgG4 was not obtained.) This was considered consistent with IgG4-associated orbital inflammatory pseudotumor with sclerosing features. The patient was initially treated with prednisone and then transitioned to intravenous rituximab as first-line therapy and had an excellent response with no recurrence at 2 years following therapy.
IgG4-associated disease is a relatively newly described, heterogeneous entity, initially described in autoimmune pancreatitis. Hamano et al. found elevated serum IgG4 level in patients with autoimmune pancreatitis, and since then, IgG4 has been used as an important marker to diagnose and re-classify select disease states previously regarded as idiopathic . The disease is characterized by IgG4-positive plasmacytic infiltrate, fibrosis of the involved organs, and often elevated serum IgG4 level. Histologic analysis of biopsy specimens is critical in diagnosing this condition . IgG4-related disease tends to affect people in the middle-aged to elderly years. The most commonly involved sites are the pancreas, the salivary and lacrimal glands, and the orbit . However, the list of involved organs continues to grow with increasing awareness.
Immune disregulation has been hypothesized as the most probable mechanism of IgG4-associated disease . IgG4 is only a minor component of four subsets of IgG. The hypothesized pathogenesis involves upregulated expression of T-helper 2 cells; cytokines such as interleukin-4,5, and 13; and regulatory cytokines such as interleukin-10 and transforming growth factor-beta [8, 10]. It has been suggested that this upregulation could be due to repeat, prolonged exposure to specific antigens. It is interesting to note that up to 40 % of patients with IgG4-related disease suffer from allergic diseases such as asthma or chronic sinusitis .
The treatment is mainly with oral corticosteroids, to which the inflammation is generally exquisitely responsive; nevertheless, patients remain on long-term steroid therapy, and relapse is common after cessation of corticosteroids . Other therapies such as radiation or immunomodulating agents are not well-described in the literature . A recent prospective, open-label trial of 30 patients using either rituximab alone (87 %) or combined with corticosteroid for the first 2 months showed disease response in 97 % of patients at month 6 . Similar positive results from several smaller case series suggest that rituximab should be considered in cases refractory to corticosteroids and/or other disease-modifying antirheumatic drugs [14–16]. The authors suggest that B-cell depletion is an effective therapy in IgG4-associated disease, thereby supporting the use of rituximab. Rituximab depletes CD20-positive B cells that differentiate into plasma cells that produce IgG4 , and this can provide more specific, targeted therapy in patients with IgG4-associated disease.
Our first patient with necrotizing scleritis was refractory to oral corticosteroids and other immunomodulating agents such as methotrexate. Rituximab was not tried given that its possibility of therapeutic advantage was not known at the time of her treatment. The second patient underwent slow prednisone taper with a maintenance dose of methotrexate; however, the vision had minimal improvement despite the quiescent disease activity. Interestingly, only one of our patients (case 3) was treated with rituximab and had an excellent outcome. Even though rituximab was not an option due to insurance in case 2, this would have been our therapy of choice.
Even though IgG4-related inflammation affects many different organs, the histopathology is remarkably similar in most cases, and this is critical in making the diagnosis. It should be noted, however, that besides the typical fibro-inflammatory histologic picture generally seen in IgG4-related disease, associations between granulomatous inflammatory diseases and IgG4 are also being discovered, thereby broadening our understanding of the potential scope of IgG4-related inflammation. For example, cases of sarcoidosis, adult orbital xanthogranuloma, and granulomatosis with polyangiitis involving relatively high amounts of IgG4-positive plasma cells on histology and/or elevated IgG4 concentrations have all been recently reported [7, 17–20]. Interestingly, the necrotizing granulomatous inflammation on histology in our first case was evident only in the enucleated globe but not in the prior episcleral biopsy. The episcleral biopsy for the most part fit the typical histologic picture of IgG4-related disease, whereas the enucleated globe revealed the overlap between granulomatous sclero-uveitis and IgG4-related inflammation in this case. Accordingly, this case may be most properly diagnosed as granulomatosis with polyangiitis with an IgG4-related component. There are two other case reports of IgG4-related disease involving the episclera/sclera [3, 7]. In our case, the patient was much older than in the case reported by Ohno et al. , but both patients had a fibro-inflammatory mass lesion in the medial sclera. Their case underwent enucleation due to patient’s choice in the setting of diagnostic uncertainty, while ours progressed to a blind, painful eye despite aggressive immunosuppression. There was also a history of uveitis in their case, but unlike our case, no findings in the uvea were noted on histology of the enucleated globe. In a case reported by Paulus et al. , the patient was elderly, with a clinical presentation of sclero-uveitis and elevated p-ANCA, as in our case. The episcleral biopsy exhibited the typical histologic picture of IgG4-related disease, but unlike our case, the globe was not enucleated, so no histology of the uvea was available. A series of granulomatosis with polyangiitis cases reported by Chang et al.  found that cases involving the head and neck (sinonasal/orbital) were the ones most likely to exhibit an IgG4-related component on histology. Out of the six cases with elevated p-ANCA, four involved the sinonasal or orbital regions, and three of those four revealed an IgG4+/IgG+ plasma cell ratio of at least 30 %. It has also been discovered that many of the ANCA antibodies in patients with granulomatosis with polyangiitis are of the IgG4 subclass [21, 22].
Without the assistance of immunohistochemistry on histopathology, our second patient would have been diagnosed as having idiopathic hypertrophic pachymeningitis, and our third case would have been diagnosed as idiopathic orbital inflammatory pseudotumor. There are several reported cases of IgG4-related sclerosing pachymeningitis, and many of them were previously diagnosed as idiopathic hypertrophic pachymeningitis [23–25]. Lindstrom et al.  proposed a series of diagnostic criteria for IgG4-related meningeal disease: high serum IgG and/or IgG4 levels, infiltration of IgG4-positive plasma cells into the lesion, involvement of other organs possibly involved in IgG4-associated disease, exclusion of other diseases associated with high-serum IgG4 levels (e.g., atopic dermatitis, parasitic infections, pemphigus), exclusion of other diseases that could cause pachymeningitis, and good response to corticosteroids. Our case met the majority of diagnostic criteria except our patient had minimal response to steroids. Optic neuropathy in idiopathic hypertrophic pachymeningitis was shown to respond to therapy in six out of eight affected patients described by Kupersmith et al. . Our patient may not have responded because of the duration and extent of the disease process prior to treatment.
IgG4-related disease is an idiopathic, multi-organ inflammatory state that can manifest as chronic, relapsing sclerosing inflammation in virtually any organ system. Ocular/orbital manifestations include idiopathic orbital inflammation, pachymeningitis, or sclero-uveitis. IgG4-associated disease is an important diagnosis to make given that it can guide more specific management. Making the diagnosis prevents further extensive diagnostic testing and multiple biopsies while allowing more specific and aggressive immunosuppression. Treatment may be different depending on the involved organ systems. Systemic corticosteroids are generally the first-line therapy currently, but rituximab can be combined or used as an alternative if patients have contraindications to corticosteroids; furthermore, a shift toward rituximab as first-line therapy may be seen in the future if more data on its success accumulate . Physicians should be familiar with the diagnosis and be suspicious when patients present with chronic, sclerofibrosing inflammation with multi-systemic involvement. As the understanding of this entity increases, more specific diagnostic criteria and treatment will likely develop.
Perinuclear accentuated anti-neutrophil cytoplasmic antibodies
Best corrected visual acuity
Magnetic resonance imaging
Ocular coherence tomography
Polymerase chain reaction
We would like to acknowledge Dr. Morton Smith’s contribution in his expertise toward this manuscript.
CL: Supported by National Institutes of Health grant no. 1K23EY0249210-01.
- Stone JH, Zen Y, Deshpande V (2012) IgG4-related disease. N Engl J Med 366(6):539–551View ArticlePubMedGoogle Scholar
- Kamisawa T, Funata N, Hayashi Y, Eishi Y, Koike M, Tsuruta K, Okamoto A, Egawa N, Nakajima H (2003) A new clinicopathological entity of IgG4-related autoimmune disease. J Gastroenterol 38(10):982–984View ArticlePubMedGoogle Scholar
- Ohno K, Sato Y, Ohshima K-I Takata K, Ando M, Abd Al-Kader L, Iwaki N, Takeuchi M, Orita Y, Yoshino T (2012) IgG4-related disease involving the sclera. Mod Rheumatol. doi:10.1007/s10165-012-0758-yGoogle Scholar
- Saeki T, Saito A, Hiura T Yamazaki H, Emura I, Ueno M, Miyamura S, Geiyo F (2006) Lymphoplasmacytic infiltration of multiple organs with immunoreactivity for IgG4: IgG4related systemic disease. Intern Med 45(3):163–167View ArticlePubMedGoogle Scholar
- Takahira M, Kawano M, Zen Y, Minato H, Yamada K, Sugiyama K (2007) IgG4-related chronic sclerosing dacryoadenitis. Arch Ophthalmol 125(11):1575–8View ArticlePubMedGoogle Scholar
- Lindfield D, Attfield K, McElvanney A (2012) Systemic immunoglobulin G4 (IgG4) disease and idiopathic orbital inflammation; removing “idiopathic” from the nomenclature? Eye 26(5):623–629View ArticlePubMed CentralPubMedGoogle Scholar
- Paulus YM, Cockerham KP, Cockerham GC, Gratzinger D (2012) IgG4-positive sclerosing orbital inflammation involving the conjunctiva: a case report. Ocul Immunol Inflamm 20(5):375–377View ArticlePubMedGoogle Scholar
- Zen Y, Fujii T, Harada K, Kawano M, Yamada K, Takahira M, Nakanuma Y. (2007) Th2 and regulatory immune reactions are increased in immunoglobin G4-related sclerosing pancreatitis and cholangitis. Hepatology 45:1538–1546View ArticlePubMedGoogle Scholar
- Zen Y, Nakanuma Y (2011) Pathogenesis of IgG4-related disease. Curr Opin Rheumatol 23(1):114–118View ArticlePubMedGoogle Scholar
- Sato Y, Notohara K, Kojima M, Takata K (2010) IgG4-related disease: historical overview and pathology of hematological disorders. Pathol Int 60(4):247–58View ArticlePubMedGoogle Scholar
- Kamisawa T, Anjiki H, Egawa N, Kubota N (2009) Allergic manifestations in autoimmune pancreatitis. Eur J Gastroenterol Hepatol 21(10):1136–1139View ArticlePubMedGoogle Scholar
- Matsushita M, Ikeura T, Fukui T, Uchida K (2008) Refractory autoimmune pancreatitis: azathioprine or steroid pulse therapy? Am J Gastroenterol 103(7):1834–5PubMedGoogle Scholar
- Carruthers MN, Topazian MD, Khosroshahi A, Witzig TE, Wallace ZS, Hart PA, Deshpande V, Smyrk TC, Chari S, Stone JH (2015) Rituximab for IgG4-related disease: a prospective, open-label trial. Ann Rheum Dis. 74(6):1171–1177View ArticlePubMedGoogle Scholar
- Khosroshahi A, Carruthers MN, Deshpande V, Unizony S, Bloch DB, Stone JH (2012) Rituximab for the treatment of IgG4-related disease. Medicine 91(1):57–66View ArticlePubMedGoogle Scholar
- Khosroshahi A, Bloch DB, Deshpande V (2010) Rituximab therapy leads to rapid decline of serum IgG4 levels and prompt clinical improvement in IgG4-related systemic disease. Arthritis Rheum 62(6):1755–1762View ArticlePubMedGoogle Scholar
- Andrew N, Kearney D, Selva D (2013) IgG4‐related orbital disease: a meta‐analysis and review. Acta Ophthalmol 91(8):694–700View ArticlePubMedGoogle Scholar
- Michel L, Clairand R, Néel A, Masseau A, Frampas E, Hamidou M (2011) Association of IgG4-related disease and sarcoidosis. Thorax 66(10):920–921View ArticlePubMedGoogle Scholar
- Mudhar HS, Bhatt R, Sandramouli S (2011) Xanthogranulomatous variant of immunoglobulin G4 sclerosing disease presenting as ptosis, proptosis and eyelid skin plaques. Int Ophthalmol 31(3):245–248View ArticlePubMedGoogle Scholar
- Singh K, Rajan KDA, Eberhart C (2010) Orbital necrobiotic xanthogranuloma associated with systemic IgG4 disease. Ocul Immunol Inflamm 18(5):373–378View ArticlePubMedGoogle Scholar
- Chang SY, Keogh KA, Lewis JE, Ryu JH, Cornell LD, Garrity JA, Yi ES (2013) IgG4-positive plasma cells in granulomatosis with polyangiitis (Wegener’s): a clinicopathologic and immunohistochemical study on 43 granulomatosis with polyangiitis and 20 control cases. Hum Pathol 44(11):2432–2437View ArticlePubMedGoogle Scholar
- Holland M, Hewins P, Goodall M, Adu D, Jefferis R, Savage CO (2004) Anti-neutrophil cytoplasm antibody IgG subclasses in Wegener’s granulomatosis: a possible pathogenic role for the IgG4 subclass. Clin Exp Immunol 138(1):183–192View ArticlePubMed CentralPubMedGoogle Scholar
- Brouwer E, Tervaert JW, Horst G, Huitema MG, van der Giessen M, Limburg PC, Kallenberg CG (1991) Predominance of IgG1 and IgG4 subclasses of anti-neutrophil cytoplasmic autoantibodies (ANCA) in patients with Wegener’s granulomatosis and clinically related disorders. Clin Exp Immunol 83(3):379–386View ArticlePubMed CentralPubMedGoogle Scholar
- Chan SK, Cheuk W, Chan KT, Chan JK (2009) IgG4-related sclerosing pachymeningitis. Am J Surg Pathol 33(8):1249–1252View ArticlePubMedGoogle Scholar
- Ni H, Piao Y, Lu D, Ma X (2011) IgG4-related idiopathic hypertrophic pachymeningitis: one case report and review of the literature. Chinese J C Neurol Neurosurg 11(5):529–533Google Scholar
- Shapiro KA, Bové RM, Volpicelli ER, Mallery RM, Stone JH (2012) Relapsing course of immunoglobulin G4-related pachymeningitis. Neurology 79(6):604–606View ArticlePubMedGoogle Scholar
- Lindstrom KM, Cousar JB, Lopes MBS (2010) IgG4-related meningeal disease: clinico-pathological features and proposal for diagnostic criteria. Acta Neuropathol 120(6):765–776View ArticlePubMedGoogle Scholar
- Kupersmith MJ, Martin V, Heller G, Shah A, Mitnick HJ (2004) Idiopathic hypertrophic pachymeningitis. Neurology 62(5):686–694View ArticlePubMedGoogle Scholar
- Khosroshahi A, Wallace ZS, Crowe JL, Akamizu T, Azumi A, Carruthers M, Chari S, Della-Torre E, Frulloni L, Goto H, Hart P, Kamisawa T, Kawa S, Kawano M, Kim MH, Kodama Y, Kubota K, Lerch MM, Lohr M, Masaki Y, Matsui S, Mimori T, Nakamura S, Nakazawa T, Ohara H, Okazaki K, Ryu JH, Saeki T, Schleinitz N, Shimatsu A et al (2015) International consensus guidance statement on the management and treatment of IgG4-related disease. Arthritis Rheumatol. doi:10.1002/art.39132PubMedGoogle Scholar
